IPT 20 - TECHNICAL DATA
Pumping speed for N2 at 10-4 Pa 20 l/s
Connection flange DN 40 CF
Weight 11.5 kg
Maximum leakage current 1 µA


IPT 50 - TECHNICAL DATA
Pumping speed for N2 at 10-4 Pa 50 l/s
Connection flange DN 100 CF
Weight 28 kg
Maximum leakage current 2 µA


IPT 100 - TECHNICAL DATA
Pumping speed for N2 at 10-4 Pa 100 l/s
Connection flange DN 160 CF
Weight 45kg
Maximum leakage current 4 µA


IPT 200 - TECHNICAL DATA
Pumping speed for N2 at 10-4 Pa 200 l/s
Connection flange DN 160 CF
Weight 72 kg
Maximum leakage current 8 µA
